11
Signum 2 and 3 only:
I Press to view either application data
or manual tare values, depending
on the key pressed subsequently
(e.g., ))
Signum 2 and 3 only:
c – Quit an application or delete an
input character
Signum 3 only:
0, 1, 2 … 9
Enter numbers, letters and other
characters
Numeric Input via the Keypad
(Signum 3 Only)
§ To enter numbers (one digit at a time):
Press 0, 1, 2 … 9
§ To save input:
Press the required key (e.g., )
to save manual tare input)
$ To delete a digit:
Press c
Loading a Tare Value from
the Weighing Platform
To save the weight on the
weighing platform as a tare weight:
Press the ) key
Input Through the Digital
Control Port
You can connect a remote hand switch
or foot switch to the input control line,
for use with all application programs.
Assign one of the following functions
to this switch in the Setup menu, under
Device parameters - Control input
(
ctrl io):
CTRL IO
CTRL INP
8
8.4 Universal IN
…
…
…
CTRL OUT
For a detailed list of menu items, please see
the chapter entitled “Configuration.”
Input over the ASCII Port
See page 86, “Data Input Format.”
Input using a Bar Code
Scanner or External
Keyboard
Input over a bar code scanner or
keyboard is handled by the Signum in
the same manner as keypad input:
– Weight values for tare memory
– Reference weight values for the
Counting, Neutral Measurement and
Weighing in Percent applications
– Numeric values
– Product identifiers
Signum 2 and 3 only:
Bar code scanner input can trigger
a function or load information for
display on the display and control unit.
You can configure this option in the
operating menu under
Barcode.
Con los ajustes REF y TARE se utliza el
valor del código de barras como valor
de referencia o valor de tara. Esta difer-
enciación puede realizarse también por
medio del código de barras. En barcode:
header aparece el valor en el display.
