1
st
level 2
nd
level Function
display display
Menu
appl Select and configure application programs
weigh. Basic weighing function
count. Counting
neutr.m Neutral measurement
anim.wg Averaging (animal weighing)
check.wg Checkweighing
clss. Classification
perc.wg Weighing in percent
net tot Net-total formulation
totaliz Totalizing
Fn-Key Define the function of the k key
off No function
gro net Gross/net toggling (Signum 1 only)
2.unit Show 2
nd
weight unit
res 10 10-fold increased resolution (Signum 1 only)
SQmin Show the minimum permissible sample quantity
Setup Adapt Signum to user requirements
wp1 Settings for weighing instrument on WP1
com1 Settings for the RS-232 interface
UNICOM Settings for the optional second interface
comspec Reference weigher connection: configure the A/D converter (optional)
ctrl IO Set the function of the universal input (control line)
barcode Set the bar code scanner function
prtprot Configure the printout
Utilit Operating parameters
time Set the time
Date Set the date
password Enter a password to protect menu settings
SQmin User options: – Display minimum permissible sample quantity
– Include SQmin in GLP printout
Info View device-specific information (service date, serial number, etc.)
Lang Select language for calibration, adjustment and GMP printouts
deutsch German
english English
u.s. mode English with U.S. date/time format
franc. French
ital. Italian
espanol Spanish
Operating Menu Overview
You can configure the Signum to meet
individual requirements by entering
user data and setting selected parameters
in the operating menu.
Menu levels are identified by texts, and numeric codes identify the individual settings.
= Setting/function available in Signum 1 only
= Setting/function available in Signum 2 and 3 only
Configuration
18
