Sartorius Signum 2 User Manual

Signum 1, 2 and 3 are precise and
rugged complete scales that give you
reliable weighing results.
The Signum Series of compact scales
includes models with strain-gauge
weighing systems as well as versions
equipped with monolithic technology,
using the principle of electromagnetic
force compensation.
These compact industrial scales offer
the following special features:
– Rugged and durable Sartorius quality
– Flexible options for display unit
installation
– Wide range of configuration options
for customized operation
– Variety of optional data interfaces
– Optional IP65 protection from dust and
jets of water
– Optional versions for use in zone 2
and 22 hazardous areas
– High quality workmanship and materi-
als
– Choice of application levels
– Available in weighing capacities
between 3 kg and 60 kg; choice of res-
olutions available for each capacity
– Verifiable models in accuracy
classes k (SIWS) and l (SIWR)
– Preload values can be defined
(for equipment installed on the scale)
Additional features include:
– Large keys with positive click action
– Numeric and alphabetic input
– Large backlit 14-segment display
– Connectivity for two weighing plat-
forms (digital platform or, using an
optional A/D converter, analog plat-
form)
Advantages in routine weighing tasks:
– Fast response times
– Independence from location of platform
installation
– Designation of weight values with up
to 4 lines of alphanumeric text
– Flexibility afforded by diversity of
interfaces
– Security through password protection
Range of Models
Three different types of weighing tech-
nology are used in the Signum Series,
offering different performance levels:
Signum Regular
(SIWRDCP Models)
– Standard weighing system
(all SIWR models)
– Resolutions up to 35,000d
– Models verified at the factory for use
in legal metrology, Class l, with:
2+3000/3500e (dual range);
1+6000/7500e and
1+3000e (single range)
– The single-range scales with variable
scale intervals are available with your
choice of fixed or adjustable fine range
Signum Advanced
(SIWADCP Models)
– Mechatronic weighing system
(all SIWA… Models)
– Resolutions up to 65,000d
(Models SIWABBP)
– Mechatronic weighing system
– Resolutions up to 150,000d
Signum Supreme
(SIWSDCP Models)
– Monolithic weighing system
(all SIWS Models)
– Resolutions up to 350,000d
(all SIWSBBP Models)
– Monolithic weighing system
– Resolutions up to 620,000d
– Models verified at the factory for use
in legal metrology, Class K, with:
1+30,000e; 1+62,000e (e=d);
1+6000e; 31,000e,61.000e
(single and dual range);
16,000e (single and dual range, each
with internal motorized calibration
weight)
– The single-range scales with variable
scale intervals are available with your
choice of fixed or adjustable fine range
Signum Supreme featuring
a stainless steel housing
(SIWSDCS Models)
– Monolithic weighing system
(all SIWS models)
– Resolutions up to 350,000d
– Models verified at the factory for use in
legal metrology, Class K, with:
1+30,000e (e=d); 1+6000e; 35,000e
(single and dual range); 16,000e
(single and dual range, each with
internal motorized calibration weight)
– The dual range scales are available with
your choice of fixed or adjustable fine
range
Signum Regular, Advanced and
Supreme models are all available with
applications levels 1, 2 and 3.
Symbols
The following symbols are used in
these instructions:
§ denotes general operating instructions
$ indicates instructions for exceptional
cases
> describes the outcome of an
operating step
!indicates a hazard
For technical advice on applications,
call the hotline at:
Phone (in Germany):
+49(0)551.308.4440
Fax (in Germany):
+49(0)551.308.4449
Intended Use
2
