Satec PM130EH SERIES User Manual

21
Parameter 16-bit Register 32-bit Point R/W Unit Range/Scale
1
Reg. Cnv. Register ID Low High
kW L2 7343 LIN3 13966-13967 0x1107 R kW -Pmax Pmax
kW L3 7344 LIN3 13968-13969 0x1108 R kW -Pmax Pmax
kvar L1 7345 LIN3 13970-13971 0x1109 R kvar -Pmax Pmax
kvar L2 7346 LIN3 13972-13973 0x110A R kvar -Pmax Pmax
kvar L3 7347 LIN3 13974-13975 0x110B R kvar -Pmax Pmax
kVA L1 7348 LIN3 13976-13977 0x110C R kVA 0 Pmax
kVA L2 7349 LIN3 13978-13979 0x110D R kVA 0 Pmax
kVA L3 7350 LIN3 13980-13981 0x110E R kVA 0 Pmax
Power factor L1 7351 LIN3 13982-13983 0x110F R 0.001 -1.000 1.000
Power factor L2 7352 LIN3 13984-13985 0x1110 R 0.001 -1.000 1.000
Power factor L3 7353 LIN3 13986-13987 0x1111 R 0.001 -1.000 1.000
Voltage THD L1/L12
6
7354 LIN3 13988-13989 0x1112 R 0.1% 0 999.9
Voltage THD L2/L23
6
7355 LIN3 13990-13991 0x1113 R 0.1% 0 999.9
Voltage THD L3
6
7356 LIN3 13992-13993 0x1114 R 0.1% 0 999.9
Current THD L1 7357 LIN3 13994-13995 0x1115 R 0.1% 0 999.9
Current THD L2 7358 LIN3 13996-13997 0x1116 R 0.1% 0 999.9
Current THD L3 7359 LIN3 13998-13999 0x1117 R 0.1% 0 999.9
K-Factor L1 7360 LIN3 14000-14001 0x1118 R 0.1 1.0 999.9
K-Factor L2 7361 LIN3 14002-14003 0x1119 R 0.1 1.0 999.9
K-Factor L3 7362 LIN3 14004-14005 0x111A R 0.1 1.0 999.9
Current TDD L1 7363 LIN3 14006-14007 0x111B R 0.1% 0 100.0
Current TDD L2 7364 LIN3 14008-14009 0x111C R 0.1% 0 100.0
Current TDD L3 7365 LIN3 14010-14011 0x111D R 0.1% 0 100.0
Voltage L12 7366 LIN3 14012-14013 0x111E R V 0 Vmax
Voltage L23 7367 LIN3 14014-14015 0x111F R V 0 Vmax
Voltage L31 7368 LIN3 14016-14017 0x1120 R V 0 Vmax
Average total values
Total kW 7456 LIN3 14336-14337 0x1400 R kW -Pmax Pmax
Total kvar 7457 LIN3 14338-14339 0x1401 R kvar -Pmax Pmax
Total kVA 7458 LIN3 14340-14341 0x1402 R kVA 0 Pmax
Total PF 7459 LIN3 14342-14343 0x1403 R 0.001 -1.000 1.000
Average auxiliary values
Reserved 7496 14464-14465 0x1500 R 0 0
Neutral current 7497 LIN3 14466-14467 0x1501 R A 0 Imax
Frequency 7498 LIN3 14468-14469 0x1502 R 0.01Hz 0 100.00
2
Voltage unbalance 7499 LIN3 14470-14471 0x1503 R 1% 0 300
Current unbalance 7500 LIN3 14472-14473 0x1504 R 1% 0 300
Present demands
Volt demand L1/L12
5
7536 LIN3 14592-14593 0x1600 R V 0 Vmax
Volt demand L2/L23
5
7537 LIN3 14594-14595 0x1601 R V 0 Vmax
Volt demand L3/L31
5
7538 LIN3 14596-14597 0x1602 R V 0 Vmax
Ampere demand L1 7539 LIN3 14598-14599 0x1603 R A 0 Imax
Ampere demand L2 7540 LIN3 14600-14601 0x1604 R A 0 Imax
Ampere demand L3 7541 LIN3 14602-14603 0x1605 R A 0 Imax
Block kW demand 7542 LIN3 14604-14605 0x1606 R kW 0 Pmax
Reserved 7543 14606-14607 0x1607 R 0 0
Block kVA demand 7544 LIN3 14608-14609 0x1608 R kVA 0 Pmax
Sliding window kW demand 7545 LIN3 14610-14611 0x1609 R kW 0 Pmax
Reserved 7546 14612-14613 0x160A R 0 0
Sliding window kVA demand 7547 LIN3 14614-14615 0x160B R kVA 0 Pmax
Reserved 7548 14616-14617 0x160C R 0 0
Reserved 7549 14618-14619 0x160D R 0 0
Reserved 7550 14620-14621 0x160E R 0 0
Accumulated kW demand
(import)
7551 LIN3 14622-14623 0x160F R kW 0 Pmax
Reserved 7552 14624-14625 0x1610 R 0 0
Accumulated kVA demand 7553 LIN3 14626-14627 0x1611 R kVA 0 Pmax
Predicted sliding window kW
demand
7554 LIN3 14628-14629 0x1612 R kW 0 Pmax
Reserved 7555 14630-14631 0x1613 R 0 0

Satec PM130EH SERIES Specifications

General

Display	LCD
Frequency	50/60 Hz
Communication	RS-485, Modbus RTU
Digital Outputs	2 relay outputs
Data Logging	Yes
Measurement Type	Power, Energy, Harmonics
Current Input	1A or 5A
Mounting	Panel Mount
Power Supply	85-265V AC/DC
Digital Inputs	2
Analog Outputs	Up to 4
Operating Temperature	-20 to 70°C
Dimensions	96 x 96 mm
Weight	0.5kg
