Satec PM130EH SERIES User Manual

23
Parameter 16-bit Register 32-bit Point R/W Unit Range/Scale
1
Reg. Cnv. Register ID Low High
Fundamental's (H01) real-time total values
Total fundamental kW 8336 LIN3 17152-17153 0x2A00 R kW -Pmax Pmax
Total fundamental kvar 8337 LIN3 17154-17155 0x2A01 R kvar -Pmax Pmax
Total fundamental kVA 8338 LIN3 17156-17157 0x2A02 R kVA 0 Pmax
Total fundamental PF 8339 LIN3 17158-17159 0x2A03 R 0.001 -1.000 1.000
Minimum real-time values per phase (M)
Voltage L1/L12
5
8416 LIN3 17408-17409 0x2C00 R V 0 Vmax
Voltage L2/L23
5
8417 LIN3 17410-17411 0x2C01 R V 0 Vmax
Voltage L3/L31
5
8418 LIN3 17412-17413 0x2C02 R V 0 Vmax
Current L1 8419 LIN3 17414-17415 0x2C03 R A 0 Imax
Current L2 8420 LIN3 17416-17417 0x2C04 R A 0 Imax
Current L3 8421 LIN3 17418-17419 0x2C05 R A 0 Imax
Minimum real-time total values (M)
Total kW 8456 LIN3 17536-17537 0x2D00 R kW -Pmax Pmax
Total kvar 8457 LIN3 17538-17539 0x2D01 R kvar -Pmax Pmax
Total kVA 8458 LIN3 17540-17541 0x2D02 R kVA 0 Pmax
Total PF
3
8459 LIN3 17542-17543 0x2D03 R 0.001 0 1.000
Minimum real-time auxiliary values (M)
Reserved 8496 17664-17665 0x2E00 R 0 0
Neutral current 8497 LIN3 17666-17667 0x2E01 R A 0 Imax
Frequency 8498 LIN3 17668-17669 0x2E02 R 0.01Hz 0 100.00
2
Maximum real-time values per phase (M)
Voltage L1/L12
5
8736 LIN3 18432-18433 0x3400 R V 0 Vmax
Voltage L2/L23
5
8737 LIN3 18434-18435 0x3401 R V 0 Vmax
Voltage L3/L31
5
8738 LIN3 18436-18437 0x3402 R V 0 Vmax
Current L1 8739 LIN3 18438-18439 0x3403 R A 0 Imax
Current L2 8740 LIN3 18440-18441 0x3404 R A 0 Imax
Current L3 8741 LIN3 18442-18443 0x3405 R A 0 Imax
Maximum real-time total values (M)
Total kW 8776 LIN3 18560-18561 0x3500 R kW -Pmax Pmax
Total kvar 8777 LIN3 18562-18563 0x3501 R kvar -Pmax Pmax
Total kVA 8778 LIN3 18564-18565 0x3502 R kVA 0 Pmax
Total PF
3
8779 LIN3 18566-18567 0x3503 R 0.001 0 1.000
Maximum real-time auxiliary values (M)
Reserved 8816 18688-18689 0x3600 R 0
Neutral current 8817 LIN3 18680-18681 0x3601 R A 0 Imax
Frequency 8818 LIN3 18682-18683 0x3602 R 0.01Hz 0 100.00
2
Maximum demands (M)
Max. volt demand L1/L12
5
8856 LIN3 18816-18817 0x3700 R V 0 Vmax
Max. volt demand L2/L23
5
8857 LIN3 18818-18819 0x3701 R V 0 Vmax
Max. volt demand L3/L31
5
8858 LIN3 18820-18821 0x3702 R V 0 Vmax
Max. ampere demand L1 8859 LIN3 18822-18823 0x3703 R A 0 Imax
Max. ampere demand L2 8860 LIN3 18824-18825 0x3704 R A 0 Imax
Max. ampere demand L3 8861 LIN3 18826-18827 0x3705 R A 0 Imax
Reserved 8862 18828-18829 0x3706 R 0 0
Reserved 8863 18830-18831 0x3707 R 0 0
Reserved 8864 18832-18833 0x3708 R 0 0
Max. sliding window kW demand 8865 LIN3 18834-18835 0x3709 R kW 0 Pmax
Reserved 8866 18836-18837 0x370A R 0 0
Max. sliding window kVA
demand
8867 LIN3 18838-18839 0x370B R kVA 0 Pmax
1
For the parameter limits, see Note
1
to Table 5-1
2
The actual frequency range is 45.00 - 65.00 Hz
3
Absolute min/max value (lag or lead)
4
The exported energy registers are read as positive unsigned long (32-bit) integers
5
When the 4LN3 or 3LN3 wiring mode is selected, the voltages will be line-to-neutral; for any other wiring mode,
they will be line-to-line voltages.
6
In the 4LN3, 4LL3, 3LN3, 3LL3 and 3DIR2 wiring modes, the harmonic voltages will represent line-to-neutral
voltages; in the 3OP2 and 3OP3 wiring modes, they will comprise L12 and L23 line-to-line voltages.

Satec PM130EH SERIES Specifications

General

Display	LCD
Frequency	50/60 Hz
Communication	RS-485, Modbus RTU
Digital Outputs	2 relay outputs
Data Logging	Yes
Measurement Type	Power, Energy, Harmonics
Current Input	1A or 5A
Mounting	Panel Mount
Power Supply	85-265V AC/DC
Digital Inputs	2
Analog Outputs	Up to 4
Operating Temperature	-20 to 70°C
Dimensions	96 x 96 mm
Weight	0.5kg
