SATEL INTEGRA 41
Required settings of the ETHM-1 Plus / ETHM-1 module:
• programmed: address of computer with DLOAX program (SERVER) and number of TCP
port used for communication.
Required settings of the DLOADX program for direct communication with the module:
• programmed: number of TCP port used for communication and data encryption key
(DLOADX KEY) or selected set of parameters “LAN: ETHM-1, Address n” (settings of the
ETHM-1 Plus / ETHM-1 module with address “n” will be used).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: DLOADX <- ETHM/INT-GSM” in it.
3. In the LCD keypad connected to the control panel, start the ETHM-1 DLOADX function
([code] DOWNLOADING ETHM-1 DLOADX). The function is available to the
installer, administrator and the user having the DOWNLOADING STARTING right.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Initiating connection by SMS message
The INT-GSM / INT-GSM LTE module must be connected to the ETHM-1 Plus
module. If connection via Ethernet cannot be established, an attempt will be made to
establish communication via the cellular data network.
Required settings of the ETHM-1 Plus module:
• programmed: address of computer with DLOAX program (DLOADX SERVER) and number
of TCP port used for communication,
• programmed control command, which, if sent in the SMS message, will initiate connection
with the DLOADX program.
Required settings of the DLOADX program for direct communication with the module:
• programmed: number of TCP port used for communication and data encryption key
(DLOADX KEY).
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select “TCP/IP: DLOADX <- ETHM/INT-GSM” in it.
3. Send to the INT-GSM / INT-GSM LTE module the following SMS message:
xxxx= (“xxxx” – the control command to initiate establishment of communication with
DLOADX program) – the module is to connect to the computer address programmed in
the module,
xxxx=aaaa:p= (“xxxx” – the control command to initiate establishment of communication
with DLOADX program; “aaaa” – address of the computer with DLOADX program (IP
address or domain name); “p” – TCP port) – the module is to connect to the computer
whose address has been given in the SMS message and use for communication the
TCP port given in the SMS message.
4. The DLOADX program will inform you about establishing connection by means of
a suitable message.
Establishing connection via the SATEL server
For communication via the SATEL server, the ports of 1024-65535 range are used as
outgoing ports. These ports must not be blocked.
