SATEL INTEGRA 39
Connection initialized by the control panel – built-in GSM communicator (CSD
transmission) only INTEGRA 128-WRL
Control panel settings:
• program the telephone number of modem connected to computer,
• configure the GSM communicator.
DLOADX program settings:
• configure the modem communication parameters.
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select the “Modem - INTEGRA with ext. modem” in
it. A window will open in which modem initialization information will be displayed.
3. In the LCD keypad connected to the control panel, start the START DWNL-CSD function
([code] DOWNLOADING START DWNL-CSD). The function is available to the installer,
administrator and user having the DOWNLOADING STARTING right.
4. The control panel will call the programmed computer telephone number.
5. The DLOADX program will answer the connection automatically or the program user must
accept establishing the communication (which depends on the settings programmed in
the “Configuration” window, “Modem” tab). A suitable message will inform about the
connection being established.
Connection initiated by the control panel – external modem
Control panel settings:
• program the telephone number of modem connected to computer,
• enable the EXTERNAL MODEM option,
• if a GSM or ISDN modem is connected to the control panel, enable the MODEM
ISDN/GSM/ETHM option,
DLOADX program settings:
• configure the modem communication parameters.
1. Click on the button in the DLOADX program.
2. A drop-down menu will be displayed. Select the “Modem - INTEGRA with ext. modem” in
it. A window will open in which modem initialization information will be displayed.
3. In the LCD keypad connected to the control panel, start the START DWNL-MOD function
([code] DOWNLOADING START DWNL-MOD). The function is available to the installer,
administrator and user having the DOWNLOADING STARTING right.
4. The control panel will call the programmed computer telephone number.
5. The DLOADX program will answer the connection automatically or the program user must
accept establishing the communication (which depends on the settings programmed in
the “Configuration” window, “Modem” tab). A suitable message will inform about the
connection being established.
3.4.2 Starting remote programming via Ethernet network
Programming through the Ethernet network is possible, if the ETHM-1 / ETHM-1 Plus module
is connected to the control panel (the RS-232 ports of control panel and module must be
connected).
Before you start the remote programming via Ethernet, make sure that the local
programming is finished.
