94 Programming SATEL
• battery status – information on low battery is sent when the battery voltage drops below
11 V for more than 12 minutes (3 battery tests). The expander will kept sending this
information to the control panel until the battery voltage rises and remains above 11 V for
longer than 12 minutes (3 battery tests).
• AC power status – information on the loss of power supply is sent when the AC power loss
lasts for more than 30 seconds. The AC power restore is reported with the same delay.
Low battery information for the first zone of ACX-201 expander indicates overload of the
AUX1 or AUX2 power supply output, for the second zone – discharged battery, for the third
zone – loss of AC power..
Additional information is also sent by the ACX-220 expander if it is powered from a power
supply unit connected to the APS connector. In the case of this expander, the low battery
information provided by the control panel means:
first zone – power supply overload,
second zone – low battery,
third zone – AC mains loss.
9.3.4 230 V AC wireless controllers
Turning on the output to which the controller is assigned turns on the relay controlling the
230 V AC circuit (turns on power).
The zone to which the wireless controller is assigned is activated when the relay controlling
the 230 V AC circuit is turned on [operating modes 1 and 2] / ASW-200 controller button is
pressed [operating mode 0] / ASW-210 controller input is activated [operating mode 0] (select
the appropriate zone type).
10. Timers
The timers enable some functions to be automatically executed by the control panel
(arming/disarming, turning on/off devices connected to outputs, etc.). The timer compares the
time to that of the control panel clock and executes the selected function at the programmed
time.
10.1 Programming the timers
The timers can be programmed:
• using the keypad, in the service mode, by means of the functions available in the TIMERS
submenu,
• using the DLOADX program, in the “Timers” window.
10.2 Timer parameters
Name – individual timer name (up to 16 characters).
User edits – if this option is enabled, the users can edit the timer parameters by using the
keypad ([code] CHANGE OPTIONS TIMERS).
Parameters of the timers indicated as the controlling ones for the 120. THERMOSTAT
type output can be edited by the user even if the USER EDITS option is disabled (see:
“120. Thermostat output settings” p. 68).
[day of week] – you can program the timer start/end time for each day of the week.
Everyday – you can program the timer start/end time which will apply to those days of the
week for which no timer start/end time has been programmed.
