SATEL INTEGRA 101
• in specified time intervals. For each monitoring station, the number of days, hours and
minutes between transmission can be individually programmed. The test transmission
code will be sent:
– after a predefined period of time has elapsed since the last transmission, irrespective of
whether it was a test transmission, or the code of another event was sent (the NO SYNC.
TO LAST TRANSMISSION
option disabled),
– at predefined time intervals (the NO SYNC. TO LAST TRANSMISSION option enabled).
12.1.7 SMS reporting only INTEGRA 128-WRL
Monitoring station 1 / Monitoring station 2
Tel. Number – the telephone number of the monitoring station to which events are to be
reported in the form of SMS messages.
SMS format – the SMS message format for SMS reporting. It must be defined according to
the monitoring station requirements. The SMS message format, programmed by default in
the INTEGRA 128-WRL control panel, corresponds to the default settings of the STAM-2
monitoring station (firmware version 1.2.0 or newer) for the Contact ID format. When
programming the SMS message format, bear in mind that identifier and event code only
will be sent for the formats other than Contact ID.
Fig. 12. Typical SMS reporting settings in the DLOADX program.
12.2 Starting the reporting
12.2.1 Telephone reporting
1. Enable the REPORTING – TELEPHONE option.
2. Using the telephone options (see: “Telephone options” p. 71):
– determine how the telephone numbers should be dialed (TONE DIALING option and – in
case of the pulse dialing – PULSE DIALING 1/1,5 (OFF:1/2) option),
– determine whether the control panel, prior to dialing the number, should check the
telephone line for dialing signal (NO DIAL TONE TEST option).
3. Determine whether the event codes will be sent to both monitoring stations or to one of
them only (STATION 1 OR 2 / STATION 1 / STATION 2 / STATION 1 AND 2).
