46 Programming SATEL
– data encryption key (identical to that programmed in the GSM module).
4. Having entered the number of TCP port and data encryption key, press the “Start” button.
Activation of the server for cellular data network connection will follow.
5. Send to the GSM module the following SMS message:
zzzzzz. or zzzzzz= (“zzzzzz” – the control command programmed in the GSM module
initializing communication via the cellular data network with the DLOADX program) –
the GSM module will connect the control panel to the computer whose address is
programmed in the module,
zzzzzz=aaaa:p. or zzzzzz=aaaa:p= (“zzzzzz” – the control command programmed in the
GSM module initializing communication via the cellular data network with the DLOADX
program; “aaaa” – address of the computer with DLOADX program (IP address or
domain name); „p” – TCP port) – the GSM module will connect the control panel to the
computer whose address is given in the SMS message (the computer address
programmed in the GSM module will be ignored).
6. The DLOADX program will inform you about establishing connection by means of
a suitable message.
3.5 Control panel data file
After readout of the control panel data, you can save the data file to the computer disk. The
data file is encrypted. Default encryption prevents the data file from being opened in other
location than the disk where the DLOADX program, which was used to save the data, is
installed. You can change the default key for data encryption (“File” “Access setup” “Data
files encryption key”). If you use an encryption key other than the default one, you can open
the control panel data file in any location, after entering the encryption key.
You can export the control panel data file (“File” “Export/Import” “Export file”). Once the
file is exported, it can then be imported from any computer (“File” “Export/Import” “Import
file”). When exporting the file, you can enter the encryption key which will be required during
import of the file.
All the data files can be exported (“File” “Export/Import” “Export all”). In this case, you will
be required to enter the encryption key.
4. System structure
The system can be subdivided into objects (subsystems). Partitions are assigned to each
object and zones are assigned to partitions.
4.1 Objects
The objects are treated as separate alarm systems. By default, one object is created in the
control panel. New object can be created:
• using the keypad, in the service mode, by means of the NEW OBJECT function
(STRUCTURE SYSTEM OBJECTS NEW OBJECT) – having started the function, select
the object to be created (after an object is created, the LCD keypad will automatically
display the functions to allow you to assign partitions to objects and to name the objects),
• using the DLOADX program, in the “Structure” window, “System” tab, after clicking on the
system name – a new object will be created after you click on the “Add” button.
