32 Programming SATEL
Initializing – lines containing the modem initialization commands:
for communication with built-in control panel 300 bps modem: in the first line E0V1Q0
– a command required for proper operation of the modem. You should also add the
operating mode selection: B0 or B1 (selection of transmission format: V.21 or Bell103),
and the commands limiting transmission rate over telephone line to 300 bps. These are
commands specific for the given modem model, e.g. N0S37=3, F1 or +MS=1,0,300,300
etc. Information on how to limit the modem transmission rate is usually included in the
device manual. The other line should contain the following commands:
S0=0S9=1S7=120S10=255. They are necessary for correct operation.
for communication with external analog modem connected to the control panel: in
the first line E0V1Q0, the second line S0=0S7=120. It is not recommended to insert
additional commands to limit the modem transmission rate, unless this is required by
the modems used, or the telephone link quality.
for communication through ISDN or GSM modem: in the first line E0V1Q0, the second
line S0=0. Depending on the modems used, you will have to use additional
commands to set the identical transmission format, as in the control panel
modem, i.e. specific for the given modem. V.110 format is intended for the GSM
modems.
Modem ISDN – enable this option, if communication is to be effected through an ISDN or
GSM modem.
3.2.3 Ethernet communication parameters
Programming the parameters
Control panel settings
Settings related to working in conjunction with the Ethernet module which enables
communication over Ethernet can be configured when programming the telephone options
(see: “Telephone options” p. 71).
Ethernet module settings
For description of the configuring, please refer to the Ethernet module manual.
DLOADX program settings
The settings for communication using the ETHM-1 Plus / ETHM-1 module can be configured
in the “Connection settings” window (the command for opening this window is available in the
“Communication” menu; you can also use the Ctrl+R key combination).
Description of the parameters
Control panel settings
Options related to working in conjunction with the Ethernet module are described in section
“Telephone options” (p. 71).
Ethernet module settings
For description of parameters and options, please refer to the Ethernet module manual.
DLOADX program settings
These settings apply not only to communication via Ethernet but also via cellular data
network, provided that the INT-GSM / INT-GSM LTE module is connected to the
ETHM-1 Plus module.
TCP/IP connection: DLOADX – ETHM/INT-GSM
The settings below apply to direct communication with the module.
