Section 1: Introduction
CG4 Series Operator Manual Page 1-1
INTRODUCTION
Thank you for your investment in this SATO printer product.
This Operators Manual contains the basic information about the installation, setup, configuration, operation
and maintenance of the printer.
A total of eight topics are covered herein, and they are organized as follows:
Section 1: Introduction
Section 2: Installation
Section 3: Operation and Configuration
Section 4: Troubleshooting
Section 5: Cleaning and Maintenance
Section 6: General Specifications
Section 7: Interface Specifications
Section 8: Appendix
It is recommended that you read carefully and become familiar with each section before installing and
maintaining the printer. Refer to the Table Of Contents at the front of this manual to search for the relevant
information needed. All page numbers in this manual consist of a section number followed by the page
number within the stated section.
This section assists you in unpacking the printer from the shipping container. You will also be guided through
a familiarization tour of the main parts and controls.
The following information is provided herein:
• Features of the printer
• Unpacking
• Parts Identification
1.1 FEATURES OF THE PRINTER
The CG4 Series is 4 inch Compact Desktop printer (Thermal Transfer or Direct Thermal). With a 32-bit RISC
CPU, 4 ips print speed, and 4MB Flash Memory, the CG4 Series is an economical printer with numerous
features making it suitable for a wide range of applications. The key features of the CG4 Series are:
• High Print Resolution with crisp printing quality (203dpi or 305dpi)
• Multiple Interface
• Cutter and Dispenser Printer Options
• Linerless Label Support
• Easy Media Loading
• Standalone Capability using Keypad
• Tool-less changing of print head and platen roller for easier maintenance
• Codepage Support and Emulations
• Anti-Microbial casing is ideally suited for clinical environments or food processing industry
• Safety Top Cover Latch
• Distinctive Chassis color

SATO CG408TT Specifications

General

Print Method	Thermal Transfer / Direct Thermal
Resolution	203 dpi
Max Print Width	104 mm
Memory	8MB Flash ROM, 16MB SDRAM
Print Speed	4 ips
Media Sensor	Reflective and Transmissive
Interface	USB, RS232C
Optional Interfaces	Ethernet
Media Type	Roll, Fanfold
Media Width	22 mm to 118 mm
Media Thickness	0.06 mm - 0.2 mm
Ribbon Width	40 mm to 110 mm
Power Supply	AC 100-240V, 50/60 Hz
