Section 2. Installation
Page 2-4 PN 9001105 Rev. A SATO M-84PRO
DIP Switch
Cover
LCD
Display
Power Switch
Ribbon Rewind
Spindle
Ribbon Supply
Spindle
Side Access
Door
Top Access
Door
Label Roll Retainer
Label Hold Down
Label Supply Spindle
Label Guide
Print Head
Head Latch
Platen
