Rack Install
The PAV-VIM1C can be attached to a rack with the connections facing front or rear, to fit the needs of the installation. To attach a PAV-VIM1C do the
following:
1. Remove the brackets for all the PAV-VIM1C to be installed.
2. Remove the four case screws from one end of the PAV-VIM1C.
3. Align the case screws with the bracket.
4. Replace the screws attaching the bracket.
5. Repeat steps 2 to 4 for each PAV-VIM1C.
6. Align the handle with screw holes.
7. Attach the handle with the screws provided.
8. Repeat steps 6 and 7 for the second handle.
9. Install the shelf in the rack using rack screws (not supplied).
10. Install each PAV-VIM1C with the bracket attached using the
captive screws on the bracket.
TIP! Savant recommends to space out the PAV-VIM1Cs when
using the RCK-PAVVM8, if the rack mount is not full.
