5.6. Source Profiles
Some device profiles require an “AVoIP” version of the profile to be compatible with the control connections of the Video over IP devices. Below is an
image of one of these profiles with the AVoIP tag highlighted.
?
Components
All Control Types
All Components
All Manufacturers
Comcast X1 Cable Box
4
Components TL Rating Comment
Comcast
X1 Cable Box (AVoIP) (Cisco RNG 110,...
This example applies to a number of device types. If multiple Profiles matching the model appear in the Library, select the version with the AVoIP tag
as shown if the unit will be controlled via an Audio/Video over IP port. For more information on available profiles see the Savant IP Video: AV Devices
May Require Alternate Profile for IR Control Application Note on the Savant Customer Community.
IMPORTANT! AVoIP Profiles are only required with da Vinci 8.7.1 and lower runtime software.
5.7. Expansion
The Savant IP Video system has unlimited scalability. The limit is the amount of ports on the 10G switch. For instance, on a 96 port 10G Network
switch: 1x95, 2x94, and so on up to 95x1. In addition, add as many receivers required in the installation based on the number of displays.
Every source and display require a port on the 10G switch.
5.8. AVB Expansion
Savant IP Audio devices and IP Video devices with Audio Processing can be connected using a Savant certified AVB/TSN switch.
IMPORTANT! The maximum number of AVB devices is governed by the active da Vinci version. For the exact maximum in the system being deployed
reference the Release Readme for that release found on the Savant Customer Community.
