3.4. IR Wiring
PAV-VIMxS/PAV-VIMAPxS
IR connections are made using a 3-pin Control Connector supplied
with the device. The wire slips into the hole and locks with a screw
located at the top of the connector.
PAV-VOMVP1x/PAV-VOM1C/PAV-VIMVP1x/PAV-VIM1C
IR connection are made using 3.5 mm IR Emitter supplied with the
device.
IMPORTANT: IR Wiring Precautions
– Ensure that all IR emitters are within 15 feet (4.6 meters) from the controller’s location.
– Use of 3rd party blinking IR emitters with Talk Back is not recommended. These types of emitters can draw voltage away from the IR signal
that can degrade IR performance.
3.5. RS-232 Wiring
PAV-VIMxS/PAV-VIMAPxS
Serial control connections are made using a 3-pin Control
Connector supplied with the device. The wire slips into the hole
and locks with a screw located at the top of the connector.
PAV-VIMVP1x/PAV-VOMVP1x/PAV-VIM1C/PAV-VOM1C
Serial control connection are made using a 4-pin Control
Connector supplied with the device. The wire slips into the hole
and locks with a screw located at the top of the connector.
3
2
1
PIN
1
IR -
PIN 2
IR +
PIN
3
Not Used
Out
G
GRXTX12V
432
1
PIN 1 12V Do Not Use
PIN 2Transmit
PIN 3 Receive
PIN 4Ground
3
2
1
PIN
1
Ground
PIN
2Transmit
PIN
3
Receive
Rx
Tx
G
