6. Best Practices
Once the system is installed and the configuration has been uploaded to the Host, this section shows some best practices for testing a Savant IP Video
system.
PAV-VIMxS/PAV-VIMVP1x/PAV-VIM1C
Initial Audio and Video setup/testing should be done using the default Extended Display Identification Data (EDID). The default EDID has support for PCM
audio up to 8 channels and video resolutions up to 4k 60hz 4:2:0 8-bit.
PAV-VIMAPxS
Initial Audio and Video setup/testing should be done using the default EDID. The default EDID has support for video resolutions up to 4k 60hz 4:2:0 8-bit,
and most encoded audio formats.
Enhanced Video
HDR 10+ HDR Deep Color
Video EDID Settings
2160p 24Hz
Format:
Frequency:
4096x2160p
24Hz
Aspect ratio:
Format type:
256:135
short
2160p 60Hz
Format:
Frequency:
3840x2160p
60Hz
Aspect ratio:
Format type:
16:9
short
2160p 50Hz
Format:
Frequency:
3840x2160p
50Hz
Aspect ratio:
Format type:
16:9
short
2160p 60Hz
Format:
Frequency:
4096x2160p
60Hz
Aspect ratio:
Format type:
256:135
short
2160p 50Hz
Format:
Frequency:
4096x2160p
50Hz
Aspect ratio:
Format type:
256:135
short
Unknown video mode
Format:
Frequency:
1920x540
60.05Hz
Aspect ratio:
Format type:
32:9
detailed
YCbCr 4:2:0 Only
YCbCr 4:2:0 Only
YCbCr 4:2:0 Only
YCbCr 4:2:0 Only
Check boxes
selected by default
Testing
Every source should be tested with every A/V zone. Savant recommends testing a single source with one A/V zone at a time.
1. Activate the first Video source to a single Zone.
2. Does Video pass?
A. NO: Check System Monitor for the resolution of the Input and then the output, if using a video processing VOM scale the VOM to 1080p. If 1080P
passes, the TV or the HDMI cable may not support the current resolution of the source that is being routed to the TV through the Savant Video
system.
B. YES: Check Audio
3. Does Audio pass?
A. NO: In System Monitor set the audio path policy for the PAV-VOM to “Downmix”. If audio is still not present verify audio is enabled on the source.
B. YES: Continue to the next Zone.
4. Repeat with the same source until all Video zones have been tested. Repeat with all other Video sources in the same manner as shown above.
After this testing is complete. Add more advanced EDIDs and test again.
