5.4. Adding a 10G Switch to a Configuration
This process is to add a NetGear ProSafe M4300 10G network switch to the configuration. See Savant IP Video Network Configuration Guide on the
Savant Customer Community for information on how to set up this device before its video connections are made. In an open Blueprint configuration
do the following.
1. Click Show Library.
2. In the Search bar type M4300.
3. Select the M4300 10G switch that is being used in the
deployment and drag it into a Shared Equipment zone.
4. Name the Device.
5. Place the M4300 10G switch in the Layout window.
6. Make Control Connection.
7. Select the Control Connection.
8. Open Inspector.
9. Enter the IP Address of the switch on the Host address field.
NOTES:
– The control connection is required for services to generate
correctly.
– The IP address is needed for System Monitor information to
populate (This feature as added in da Vinci 8.8 release).
– In the physical installation this control connection uses one of
the RJ-45 10G connections. This is the switch’s uplink port that
is configured in the Savant IP Video Network Configuration
Guide.
?
Enter a unique name for the component
Cancel Create
M4300 12x12F
4
?
Components
All Control Types
All Components
All Manufacturers
M4300
4
Components TL Rating Comment
Netgear
M4300-8x8F [IP]
Netgear
M4300-12x12F [IP]
Netgear
M4300-16x [IP]
2
Inspecting “Data”
?
Screens
Device
Hide DetailsEdit
Output Connector
Network Device
Input Connector
Network Device 10G
Port 13 - UPLINK
Port 1: Ethernet Port
Data
Inches
0
Ethernet
23
Control port:
Wire Length:
Units:
Wire Name:
Host address:
Wire:
Control Type:
Notes:
10.0.100.176
Inches
9
