7.3. NetGear Switch Information
The NetGear M4300 switches display status information in System Monitor. This requires a control connection to be made in Blueprint and the IP
address of the NetGear switch to be defined. This feature requires da Vinci 8.8 or higher.
Logical IOs – Lists port number and the name of the connected device. The port numbering displays as 1/0/x. The last number is the port number.
The SFP+ ports start at 1. Selecting a Logical IO can take up to 20 seconds for the status information to fully populate.
Port Information – Displays connection status of the connected port. This information is mainly used it troubleshooting.
7.4. EDID Settings
For more information on EDID settings in System Monitor see System Monitor - EDID Settings on the Savant Customer Community.
