5. Blueprint Configuration
Required Devices
– Savant Host
– IP Video Transmitter
– IP Video Receivers
– 10G Network Switch
– Video Sources
– HD/UHD Displays
5.1. Basic Blueprint Layout
Master Bedroom
Theater
Family Room
Theater
Cable TV 01
Outputs
Control Ports
HDMI Out to TV (HDMI)
IR
Cable TV 02
Outputs
Control Ports
HDMI Out to TV (HDMI)
IR
Apple TV 01
Outputs
Control Ports
HDMI (HDMI)
Ethernet (Ethernet)
Apple TV 02
Outputs
Control Ports
HDMI (HDMI)
Ethernet (Ethernet)
Blu Ray
Data
Control Ports
ETHERNET
Outputs
HDMI OUT (HDMI)
RS-232C
Savant Host
PAV VIM8S
Data
Control Ports
Video Audio Input 1
HDMI In (HDMI)
Assigned Inputs
Video Audio Input 2
HDMI In (HDMI)
Video Audio Input 3
HDMI In (HDMI)
Video Audio Input 4
HDMI In (HDMI)
Video Audio Input 5
HDMI In (HDMI)
Video Audio Input 8
HDMI In (HDMI)
Video Audio Input 7
HDMI In (HDMI)
Video Audio Input 6
HDMI In (HDMI)
Outputs
Assigned Data
Video Audio Output 1
10GbE (SFP)
Video Audio Output 2
10GbE (SFP)
Video Audio Output 3
10GbE (SFP)
Video Audio Output 4
10GbE (SFP)
Video Audio Output 5
10GbE (SFP)
Video Audio Output 6
10GbE (SFP)
Video Audio Output 7
10GbE (SFP)
Video Audio Output 8
10GbE (SFP)
M4300 12x12F
Control Ports
1
SFP Ethernet Port (SFP)
Assigned Data
2
SFP Ethernet Port (SFP)
3
SFP Ethernet Port (SFP)
4
SFP Ethernet Port (SFP)
5
SFP Ethernet Port (SFP)
8
SFP Ethernet Port (SFP)
7
SFP Ethernet Port (SFP)
6
SFP Ethernet Port (SFP)
Port 13 - UPLINK (Ethernet)
9
SFP Ethernet Port (SFP)
12
SFP Ethernet Port (SFP)
11
SFP Ethernet Port (SFP)
10
SFP Ethernet Port (SFP)
14
RJ45 Ethernet Port (RJ45)
15
RJ45 Ethernet Port (RJ45)
16
RJ45 Ethernet Port (RJ45)
17
RJ45 Ethernet Port (RJ45)
18
RJ45 Ethernet Port (RJ45)
21
RJ45 Ethernet Port (RJ45)
20
RJ45 Ethernet Port (RJ45)
19
RJ45 Ethernet Port (RJ45)
22
RJ45 Ethernet Port (RJ45)
24
RJ45 Ethernet Port (RJ45)
23
RJ45 Ethernet Port (RJ45)
Master Bedroom TV
Inputs
Control Ports
HDMI IN 3 (HDMI)
IR
MB Fiber VOM
Control Ports
Video Audio Output 1
HDMI OUT (HDMI)
Assigned Inputs
Assigned Data
Video Audio Input 1
10GbE (SFP)
IR OUT
MB Speakers
Inputs
Speaker Input (Stereo Spea...
Theater Fiber VOM
Video Audio Output 1
HDMI OUT (HDMI)
Assigned Inputs
Assigned Data
Video Audio Input 1
10GbE (SFP)
Data
LAN(C) (Ethernet)
Projector
Inputs
Control Ports
HDMI 2 (HDMI)
Ethernet (Ethernet)
Theater Speakers
Inputs
Speaker Input (Stereo Spea...
Kitchen Copper VOM
Control Ports
Video Audio Output 1
HDMI OUT (HDMI)
Assigned Inputs
Assigned Data
Video Audio Input 1
10GbE (RJ45)
IR OUT
Kitchen TV
Inputs
Control Ports
HDMI IN 3 (HDMI)
IR
Family Room TV
Inputs
Control Ports
HDMI IN 3 (HDMI)
IR
FR Copper VOM
Control Ports
Video Audio Output 1
HDMI OUT (HDMI)
Assigned Inputs
Assigned Data
Video Audio Input 1
10GbE (RJ45)
IR OUT
FR Speakers
Inputs
Speaker Input (Stereo Spea...
Network Switch
Port 1
Ethernet Port (Ethernet)
Assigned Data
Port 2
Ethernet Port (Ethernet)
Port 3
Ethernet Port (Ethernet)
SSC 0012
IR(Serial PWM) Output 1
Control Ports
IR(Serial PWM) Output 1
RS232 1 (RTS/CTS)
