4. Installation
4.1. PAV-VIMxS/PAV-VIMAPxS
The Savant IP Video Transmitter can be mounted in a 3U rack style enclosure and is compatible with all standard 19-inch NEMA rack mounts. The
rack ears need to be attached prior to installing in a rack.
4.2. PAV-VIMVP1x/PAV-VOMVP1x
The Savant IP Video Receiver or Transmitter can be placed on a solid flat surface or can be mounted on a wall with the included mounting brackets. If
installing this unit behind a display, ensure enough air can pass though the grooves on the top of the unit. This will maximize heat dissipation. Savant
recommends aligning the grooves vertically as shown below.
Power Input HDMI Output 10G Input
