SawStop CNS175 - Internal Assembly Exploded View

90 SawStop 10” Contractor Saw
No. Description Part No. Qty.
49
115V Contractor Box Assembly (includes items 48, 50-54) CNS-WA-012
1
230V Contractor Box Assembly (includes items 48, 50-54) CNS-WA-014
240/50 Hz Contractor Box Assembly (Australia only -
includes items 48, 50-54)
CNS-WA-013
220V/50 Hz Contactor Box Assembly (CNS175-CH only -
includes items 48, 50-54)
CNS-WA-034
220V/60 Hz Contactor Box Assembly (CNS175-KR only -
includes items 48, 50-54)
CNS-WA-031
50 M5 External Tooth Lock Washer CNS-09-002 2
51 M5x0.8x8 Button Head Phillips Screw CNS-09-003 2
52 Motor Control Cable Assembly CNS-09-004 1
53 Motor Cable Assembly CNS-09-005 1
54
115V Main Power Cable Assembly CNS-09-006
1
230V Main Power Cable Assembly CNS-09-007
240V/50 Hz Main Power Cable Assembly (Australia only) CNS-09-008
220V/50 Hz Main Power Cable Assembly (China only) CNS-13-002
55
M8x16x2 Washer CNS-09-009 4
56
M8x1.25x18 Socket Head Cap Screw CNS-09-010 4
57
Table Insert Lock-Down Lever CNS-10-001 1
58
M4x0.7x10 Flat Head Phillips Screw CNS-10-002 2
60
Patent Label CNS-11-001 1
