SawStop CNS175 - Internal Assembly Parts List

SawStop 10” Contractor Saw 93
No. Description Part No. Qty.
1
1.75HP, 1PH, 115/230V, 60Hz, TEFC Motor (CNS175) CNS-07-056
1
1.75HP, 1PH, 208-240V, 50Hz, TEFC Motor (CNS175-AU) CNS-08-011
1.75HP, 1PH, 220V, 50Hz TEFC Motor (CNS175-CH) CNS-14-002
2
Motor Pulley CNS-07-057
1
Motor Pulley (50 Hz motors only) CNS-08-009
3
Motor Belt CNS-07-058
1
Motor Belt (50 Hz motors with a serial number between
C083800001 - C132799999 only)
CNS-08-012
4 M5x0.8x8 Set Screw CNS-07-059 1
5 M5x5x30 Key CNS-07-060 1
6 Motor Mounting Bracket CNS-07-061 1
7 M8x1.25x20 Hex Head Bolt CNS-07-062 4
8 M8x16x2 Washer CNS-07-063 13
9 M8 Lock Washer CNS-07-064 8
10 M8x1.25 Hex Nut CNS-07-065 4
11 Motor Mount Spring CNS-07-066 1
12 Motor Mount Plate CNS-07-067 1
13 Motor Mount Axle CNS-07-068 1
14 10mm E-Style Retaining Ring CNS-07-069 2
15 1/4”-20 NC x 1/4” Set Screw CNS-07-070 2
16 M6x12 Button Head Phillips Shoulder Screw CNS-07-071 1
17 13mm E-Style Retaining Ring CNS-07-072 2
18 Motor Mounting Pin CNS-07-073 2
19 Belt Guard Assembly CNS-07-074 1
21 M5x12x1 Washer CNS-07-076 4
22 M5x0.8 Hex Nut CNS-07-077 4
23 Front Trunnion Bracket CNS-07-078 1
25 M8 External Tooth Lock Washer CNS-07-080 4
28 Tilt Shaft Inner Collar CNS-07-083 1
29 M5x0.8x5 Set Screw CNS-07-084 2
30 M10x20x2 Washer CNS-07-085 1
31 Tilt Worm Gear CNS-07-086 1
32 M4x4x16 Key CNS-07-087 1
33 Tilt Control Shaft CNS-07-088 1
34 Tilt Shaft Outer Collar CNS-07-089 1
35 M6x1.0x8 Set Screw CNS-07-090 2
36 Handwheel CNS-07-091 2
37 Lock Knob CNS-07-092 2
38 Front Trunnion CNS-07-093 1
39 M6x1.0x12 Socket Head Cap Screw CNS-07-094 3
40 Tilt Indicator CNS-07-095 1
41 M6 External Tooth Lock Washer CNS-07-096 1
42 M4x0.7x10 Pan Head Phillips Screw CNS-07-097 2
Internal Assembly Parts List
