SawStop CNS175 - Arbor and Quick-Release Clamp Exploded View

94 SawStop 10” Contractor Saw
No. Description Part No. Qty.
43 M4 Lock Washer CNS-07-098 2
44 Front Trunnion Cable Clamp CNS-07-099 1
45 Arbor Guide Plate CNS-07-100 1
46 M6x1.0x30 Socket Head Cap Screw CNS-07-101 3
47 M6 Lock Washer CNS-07-102 3
48 Arbor Guide Plate Spacer CNS-07-103 3
49 Trunnion Brace Bumper CNS-07-104 1
50 Rear Trunnion CNS-07-105 1
51 M17 External Retaining Ring CNS-07-106 2
52 Elevation Control Shaft CNS-07-107 1
53 M8x1.25 Lock Nut CNS-07-108 1
54 Elevation Threaded Rod Bearing CNS-07-109 2
55 24mm Internal Retaining Ring CNS-07-110 2
56 M10x23x3 Washer CNS-07-111 1
57 Left Hand Miter Gear CNS-07-112 1
58 M5x0.8x5 Set Screw CNS-07-113 2
59 Elevation Threaded Rod CNS-07-114 1
60 M4x4x10 Key CNS-07-115 2
61 M6x1.0x40 Set Screw CNS-07-116 1
62 M6x1.0x40 Lower Elevation Limit Socket Head Screw CNS-07-117 1
63 M6x1.0x14 Set Screw CNS-07-118 2
64 Elevation Control Shaft Mounting Bracket CNS-07-119 1
65 M6x1.0x20 Socket Head Cap Screw (includes M6 washer) CNS-07-120 2
66 Right Hand Miter Gear CNS-07-121 1
67 Elevation Control Shaft Collar CNS-07-122 1
68 Elevation Control Shaft CNS-07-123 1
69 Spacer Tube CNS-07-124 1
70 Right Torque Shaft CNS-07-125 1
71 M8x1.25x20 Socket Head Cap Screw CNS-07-126 4
72 Left Torque Shaft CNS-07-127 1
73 Cable Clamp CNS-07-128 2
74 M5x0.8x12 Pan Head Phillips Screw CNS-07-129 2
75 Dust Shroud CNS-07-130 1
77 M6x1.0x12 Button Head Socket Screw (includes M6 washer) CNS-08-023 5
78 Rear Trunnion Bracket CNS-07-134 1
79 Belt Guard Warning Label CNS-07-135 1
80 M6x1.0 Hex Nut CNS-08-015 1
81 M10x19x1.5 Plastic Washer CNS-08-021 1
82 M8x1.25x30 Hex Head Screw CNS-09-011 2
83 M8x1.25x35 Hex Head Screw CNS-09-012 2
84 CNS Remove Motor Label CNS-11-002 1
85 M5x0.8x16 Set Screw CNS-15-002 1
Internal Assembly Parts List
