SawStop CNS175 - Arbor and Quick-Release Clamp Parts List

SawStop 10” Contractor Saw 97
Arbor and Quick-Release Clamp Parts List
No. Description Part No. Qty.
1 Arbor Block CNS-07-136 1
2 Arbor CNS-07-137 1
3 M5x5x30 Key CNS-07-138 1
4 Main Arbor Bearing CNS-07-139 1
5 Electrode Shell CNS-07-140 1
6 M4x0.7x6 Pan Head Phillips Screw CNS-07-141 4
7 M4 External Tooth Lock Washer CNS-07-142 2
8 Second Arbor Bearing CNS-07-143 1
9 Arbor Spacer CNS-07-144 1
10 M20 External Retaining Ring CNS-07-145 3
11 Arbor Pulley CNS-07-146 1
12 M5x0.8x8 Set Screw CNS-07-147 2
13 Combination Saw Blade CNS-07-148 1
14 Arbor Washer CNS-07-149 1
15 Arbor Nut CNS-07-150 1
16 Pivot Shaft CNS-07-151 1
17 Elevation Block CNS-07-152 1
18 M6x1.0x8 Set Screw CNS-07-153 1
19 Retraction Bracket CNS-07-154 1
20 M8x1.25x16 Button Head Socket Screw CNS-07-155 2
21 Retraction Guide CNS-07-156 1
22 M8x16x2 Washer CNS-07-157 1
23 Retraction Spring CNS-07-158 1
24 M6x33 Hex Head Shoulder Screw CNS-07-159 1
25 M12 Brake Positioning Bolt CNS-07-160 1
26 M8 O-Ring CNS-07-161 1
27 Cartridge Bracket Spring CNS-07-162 1
28 M12x1.75 Lock Nut CNS-07-163 1
29 Arbor Guide Pin CNS-07-164 1
30 Arbor Guide Cam CNS-07-165 1
31 M5x14x1 Washer CNS-07-166 1
32 M5 Lock Washer CNS-07-167 1
33 M5x0.8x10 Socket Head Cap Screw CNS-07-168 1
34 Arbor Guide Spring CNS-07-169 1
35 M6x13x1 Washer CNS-07-170 1
36 M6x1.0x12 Socket Head Cap Screw CNS-07-171 1
37 M5x0.8x10 Button Head Socket Screw CNS-07-172 1
38 M5 External Tooth Lock Washer CNS-07-173 1
39 8-32x1/4” Button Head Socket Screw CNS-07-174 3
40 Cartridge Cable CNS-07-175 1
41 Cartridge Bracket CNS-07-176 1
