SawStop CNS175 - Housing and Table Parts List

SawStop 10” Contractor Saw 89
No. Description Part No. Qty.
1 Table CNS-07-013 1
2 Rear Lock Down Screw for Insert CNS-07-014 2
3 M6x1.0x20 Set Screw CNS-07-015 2
4 Standard Extension Wing CNS-07-016 2
5 M8x1.25x16 Hex Head Bolt CNS-07-018 8
6 M8 Lock Washer CNS-07-019 12
7 Lock-Down Standard Insert Assembly (complete) TSI-SLD 1
8 M6x1.0x9.5 Insert Leveling Screw CNS-07-021 2
9 M6x1.0x14 Set Screw CNS-07-022 2
12 M6x1.0x8 Set Screw CNS-07-025 2
13
Switch Box Assembly (includes items 16-17, 41-42) CNS-07-026 1
14 M8x1.25x12 Button Head Socket Screw CNS-07-027 4
15 M8 Lock Washer CNS-07-028 4
16 Bypass Key CNS-07-029 2
17 Switch Box Lock Out Key CNS-07-030 1
19 M6x1.0x20 Hex Head Bolt CNS-07-032 2
20 M6x13x1 Washer CNS-07-033 2
21 Cabinet CNS-07-034 1
22 Tilt Shaft Mounting Bracket CNS-07-035 1
23 M6x1.0x8 Button Head Socket Screw CNS-07-036 2
24 Switch Box Cable Grommet CNS-07-037 1
25 M5x0.8 Hex Cap Nut CNS-07-038 1
26 Switch Box Cable Clamp CNS-07-039 1
27 M5x0.8x8 Socket Head Cap Screw CNS-07-040 1
30 M5x0.8x12 Pan Head Phillips Screw CNS-07-043 1
31 M5x10x1 Washer CNS-07-044 3
32 Rear Cable Clamp CNS-07-045 1
33 M5x0.8x20 Pan Head Phillips Screw CNS-07-046 3
34 Rear Cable Grommet CNS-07-047 2
37 Blade Wrench CNS-07-050 2
39 Main Warning Label CNS-07-052 1
40
Specication Label (CNS175) CNS-07-053
1
Specication Label (CNS175-KR) CNS-14-001
Specication Label (CNS175-CH) CNS-13-003
Specication Label (CNS175-AU) CNS-15-001
41 Main Power Label CNS-07-054 1
42 System Status Label CNS-07-055 1
43 Dust Shroud Warning Label CNS-07-256 1
44 Tilt Angle Scale CNS-08-001 1
45 M5x0.8x10 Pan Head Phillips Screw CNS-08-002 2
46 Contractor Saw Label CNS-08-003 1
48 Switch Box Mounting Bracket CNS-09-001 1
Housing and Table Parts List
