SCADAmetrics EtherMeter User Manual

43
AUX I/O SETUP SELECTIONS DEFAULTS
SET AUX1
DOUT, PWRSAVHI, PWRSAVLO
DOUT:
• DIGITAL OUTPUT – FOLLOWS COMMANDS FROM MODBUS OR DF1
(OR ADAM) MASTER
PWRSAVHI:
• DIGITAL OUTPUT GOES “HI” (5V) TO TURN ON CONNECTED RADIO
OR MODEM.
PWRSAVLO:
• DIGITAL OUTPUT GOES “LO” (0V) TO TURN ON CONNECTED RADIO
OR MODEM.
( FOR PWRSAVLO AND PWRSAVHI TIMING DIAGRAMS, SEE SECTION 9,
RADIO INTERFACE.)
DOUT
SET AUX2
DOUT, DIN
DOUT:
• DIGITAL OUTPUT – FOLLOWS COMMANDS FROM MODBUS, DF1,
ETHERNET/IP, OR ADAM MASTER
DIN:
• DIGITAL INPUT – MAY BE MONITORED BY INTERROGATION FROM
MODBUS, DF1, ETHERNET/IP, OR ADAM MASTER
DOUT
SET ONTIME
N (secs)
• USED WHEN DOUT1=PWRSAVHI OR PWRSAVLO
• TIME TO LEAVE RADIO ON AFTER THE RECEIPT OF A POLL REQUEST
ADDRESSED TO THIS DEVICE.
• FOR TIMING DIAGRAM, SEE SECTION 9, RADIO INTERFACE.
60
(1 min)
SET OFFTIME
N (secs)
• AFTER RECEIPT OF POLL REQUEST AND AFTER ONTIME ELAPSED,
TIME TO LEAVE RADIO OFF.
• AFTER OFFTIME ELAPSES, RADIO WILL BE TURNED OFF AND DEVICE
WILL WAIT FOR NEXT POLL REQUEST.
• FOR TIMING DIAGRAM, SEE SECTION 9, RADIO INTERFACE.
21240
(5 hrs,54min)
SET FAILSAFE
NONE, ON, OFF
ON:
• WHEN POLL NOT RECEIVED FOR FAILTIME (SECS), TURN DIGITAL
OUTPUT(S) ON.
OFF:
• WHEN POLL NOT RECEIVED FOR FAILTIME (SECS), TURN DIGITAL
OUTPUT(S) OFF.
NONE:
• IGNORE FAILTIME.
(‘FAILSAFE’ SETTING ONLY AFFECTS DIGITAL OUTPUT 1 WHEN
DOUT1=AUTO.)
NONE
SET FAILTIME
N (secs)
WHEN POLL NOT RECEIVED AFTER FAILTIME (SECS) HAS ELAPSED,
DIGITAL OUTPUT(S) PUT INTO FAILSAFE STATE
(‘FAILSAFE’ SETTING ONLY AFFECTS DIGITAL OUTPUT 1 WHEN
DOUT1=AUTO.)
60
SET AIN1
MA, V
MA:
0 (0%) Î 4 MA
10000 (100%) Î 20 MA
V:
0 (0%) Î 0 V
10000 (100%) Î 5 V
(NOTE: FOR 0-5V INPUT, REMOVE JP1)
MA
