SCADAmetrics EtherMeter - Analog Input Setup Commands

44
SET AIN2
MA, V
MA:
0 (0%) Î 4 MA
10000 (100%) Î 20 MA
V:
0 (0%) Î 0 V
10000 (100%) Î 5 V
(NOTE: FOR 0-5V INPUT, REMOVE JP2)
MA
SET ADCONST A/D CONVERTER CONSTANT 1 - FACTORY USE ONLY
1000
SET ADSHIFT
0, 1, 2, 3, 4, 5, 6
A/D CONVERTER CONSTANT 2 - FACTORY USE ONLY
6
