SCADAmetrics EtherMeter User Manual

45
INTERFACE SETUP SELECTIONS DEFAULTS
SET LCD01
AUTO, ON, OFF
CONTROLS LCD DISPLAY OF METER #1 TOTALIZATION.
AUTO:
DISPLAY ACTIVE WHEN METER #1 DETECTED.
ON:
DISPLAY ACTIVE, REGARDLESS OF WHETHER METER 1 DETECTED.
OFF:
SUPPRESSES DISPLAY.
NOTE: FOR CONVENIENCE, ALL
LCD SCREENS ARE SEQUENTIALLY
DISPLAYED RIGHT AFTER POWERUP AND RIGHT AFTER SWITCHING
FROM SETUP MODE TO RUN MODE (DIP SWITCH #1).
AUTO
SET LCD02
AUTO, ON, OFF
CONTROLS LCD DISPLAY OF METER #2 TOTALIZATION.
AUTO:
DISPLAY ACTIVE WHEN METER #2 DETECTED.
ON:
DISPLAY ACTIVE, REGARDLESS OF WHETHER METER #2 DETECTED.
OFF:
SUPPRESSES DISPLAY.
AUTO
SET LCD03
AUTO, ON, OFF
CONTROLS LCD DISPLAY OF METER #1 FLOW RATE.
AUTO:
DISPLAY ACTIVE WHEN METER #1 DETECTED.
ON:
DISPLAY ACTIVE, REGARDLESS OF WHETHER METER #1 DETECTED.
OFF:
SUPPRESSES DISPLAY.
AUTO
SET LCD04
AUTO, ON, OFF
CONTROLS LCD DISPLAY OF METER #2 FLOW RATE.
AUTO:
DISPLAY ACTIVE WHEN METER #2 DETECTED.
ON:
DISPLAY ACTIVE, REGARDLESS OF WHETHER METER #2 DETECTED.
OFF:
SUPPRESSES DISPLAY.
AUTO
SET LCD05
ON, OFF
CONTROLS LCD DISPLAY OF POWER SUPPLY VOLTAGE.
ON:
DISPLAY ACTIVE.
OFF:
SUPPRESSES DISPLAY.
OFF
SET LCD06
ON, OFF
CONTROLS LCD DISPLAY OF ANALOG INPUT #1.
ON:
DISPLAY ACTIVE.
OFF:
SUPPRESSES DISPLAY.
OFF
