PROTECTED TYPED LOGICAL READ/WRITE WITH 3 ADDRESS FIELDS
[CMD,FNC,FILE#,FILETYPE] = [0F,A2,07,89] (READ N7 REGISTERS)
REGISTERS DESCRIPTORS
N7:0-1* METER 1 TOTAL (UNSCALED)
N7:2-3* METER 2 TOTAL (UNSCALED)
N7:4-5** FLOW 1 X 1000
N7:6-7** FLOW 2 X 1000
N7:8 ROLLOVERS – METER 1
N7:9 ROLLOVERS – METER 2
N7:10 AIN 1 (0-10000)
N7:11 AIN 2 (0-10000)
N7:12 SUPPLY VOLTS X 10
N7:13 DIGITAL STATUS BITS (See Details Next Page)
N7:14 METER 1 READ FAULT
N7:15 METER 2 READ FAULT
N7:16-17* SYSTEM UPTIME (MINUTES)
N7:18 METER 1 nDIGITS
N7:19 METER 2 nDIGITS
N7:20 METER 1 EXPONENT
N7:21 METER 2 EXPONENT
N7:22 METER 1 UNITS
N7:23 METER 2 UNITS
N7:24 METER 1 READ FAULT COUNTER
N7:25 METER 2 READ FAULT COUNTER
*DATA OCCUPYING THESE REGISTERS ARE 32-BIT UNSIGNED LONG INTEGERS.
**DATA OCCUPYING THESE REGISTERS ARE 32-BIT SIGNED LONG INTEGERS.
ALL OTHERS ARE 16-BIT SIGNED INTEGERS
[CMD,FNC,FILE#,FILETYPE] = [0F,A2,FA,85] (READ B250 REGISTERS)
INPUTS DESCRIPTORS
B250:0/0 AUX DIGITAL I/O 1
B250:0/1 AUX DIGITAL I/O 2
B250:0/2 AUX DIGITAL I/O 3
B250:0/3-7 -reserved/future-
B250:0/8 METER 1 READ FAULT
B250:0/9 METER 2 READ FAULT
B250:0/10 METER 1 FWD FLOW (Y/N)
B250:0/11 METER 2 FWD FLOW (Y/N)
B250:0/12 METER 1 REV FLOW (Y/N)
B250:0/13 METER 2 REV FLOW (Y/N)
B250:0/14-15 -reserved/future-
[CMD,FNC,FILE#,FILETYPE] = [0F,AA,0A,85] (WRITE B10 REGISTERS)
B10:0/0 AUX DIGITAL OUTPUT 1
B10:0/1 AUX DIGITAL OUTPUT 2
B10:0/2 AUX DIGITAL OUTPUT 3
B10:0/3-7 -reserved/future-
B10:0/8 RESET CNT1 to ZERO (When Meter Ch. 1 Configured As Pulse Input)
B10:0/9 RESET CNT2 to ZERO (When Meter Ch. 2 Configured As Pulse Input)
B10:0/10-15 -reserved/future-
EtherMeter N-File, B-File Register Map.
