DF1 Register N7:13 contains the 16-bit word: “Digital Status Bits”. The contents of this word

are as illustrated in the following table:

Bit Position Contents

00 (Least Significant Bit) Aux Digital I/O 1 Status (1=ON, 0=OFF)

01 Aux Digital I/O 2 Status (1=ON, 0=OFF)

02 Aux Digital I/O 3 Status (1=ON, 0=OFF)

03 -reserved/future-

04 -reserved/future-

05 -reserved/future-

06 -reserved/future-

07 -reserved/future-

08 Meter 1 Read Fault (1=Fault, 0=OK)

09 Meter 2 Read Fault (1=Fault, 0=OK)

10 Meter 1 Fwd Flow (1=Fwd Flow)

11 Meter 2 Fwd Flow (1=Fwd Flow)

12 Meter 1 Rev Flow (1=Rev Flow)

13 Meter 2 Rev Flow (1=Rev Flow)

14 -reserved/future-

15 (Most Significant Bit) -reserved/future-

For example, if Register N7:13 contains the following:

0000 1100 0000 0111 (Binary)… or 0C07 (Hexadecimal)… or 3079 (Decimal)

Then the following status conditions exist:

Aux Digital I/O 1 1 ON

Aux Digital I/O 2 1 ON

Aux Digital I/O 3 1 ON

-N/A- 0 -N/A-

Meter 1 Read Fault 0 OFF (OK)

Meter 2 Read Fault 0 OFF (OK)

Meter 1 Fwd Flow 1 ON

Meter 2 Fwd Flow 1 ON

Meter 1 Rev Flow 0 OFF

Meter 2 Rev Flow 0 OFF

-N/A- 0 -N/A-
