SCAIME Manual :
NU
-eNod4C
-E-
0418
-
196712
-F.docx
Parameter
Possible Value
Description
Input 1-4 Paramete
rs
Function
Function assigned to the relat
ed input: N
one, Zero, Tare, Clear,
start cycle, stop cycle,
Suspend cycle, Dynamic Z
ero, Manual emptyin
g, Belt fault
Logic
[Positive]-[Negative]
defines the edge (or le
vel) that triggers input functio
n
Debounced t
ime
0
–
6553 ms
Minimum required time o
f the logical inputs before th
eir
activation
Output 1-4 Param
eters
eNod4-F extern
al totalizer (Page 2)
59
61
