ScanSpeed Mini - Part List

25
8.2 Part List
* The grey colored letters are old version parts.
No. Part No. Part Name
Remark
1
C12DR90000-00
Door Ass'y (White+White)
C12DR900B0-00
Door Ass'y (Blue+Blue)
C12DR900BW-00
Door Ass'y (Blue+White)
C12DR900PW-00
Door Ass'y (Pink+White)
20 C12BD00120-02
Main Board Ass`y - mini
21 C12DR02420-01
Tension Bar(Old)
21 C12DR02420-02
Tension Bar(New)
22 C12DR05420-00
Tension Bar Spring
23 C12DR02520-02
Tension Bar Holder
24 C12CS00533-02
Panel(Back)-mini
25 C12DR04420-01
Hinge Pin
26 C99DR06920-00
Flange Bearing
An instrument requires 2ea.
27 C12CS04120-01
Spacer for Foot
An instrument requires 4ea.
28 C12RB00920-00
Foot, rubber
An instrument requires 4ea.
29 C12CS00233-07
Case(BOTTOM)-mini
30 C12RB00120-02
Anti-vibration Damper
An instrument requires 3ea.
50 C12CS00120-03
Case(TOP) White-mini
C12CS00120-B0
Case(TOP) Blue-mini
C12CS0012P-00
Case(TOP) Pink-mini
51 C12BD00223-00
Display Board-mini(A7)
C12EL08020-00
Cable(Display)
52 C12CS04020-02
Overlay-mini
60
C12MT90100-01
Final Motor Assembly (110V)-mini
C12MT90200-01
Final Motor Ass'y(220V)-mini
61 C12MT80100-01
Motor Ass'y (110V)-mini
C12MT80200-01
Motor Ass'y (220V)-mini
62 C12MT80700-00
RPM Sensor ASS'Y-mini
80
C12DR90200-00
Door Lock ASS`Y-mini(220V)
C12DR90100-00
Door Lock ASS`Y-mini(110V)
80-1 C12DR90200-01
Door Lock ASS`Y-mini(220V)
81
C12DR90100-01
Door Lock ASS`Y-mini(110V)
C12DR82000-00
Latch Body Ass'y
82 C12EL03110-02
Solenoid-220V
C12EL03010-02
Solenoid-110V
83 C12EL90120-01
Door Sensor Ass`y-mini
83-1 C12EL90120-02
Door Sensor Ass`y-mini
84 C12DR03433-00
Bracket(Door Sensor)
GRF-m2.0-12-LA-01
Plastic rotor lid of GRF-m2.0-12 for mini
