Hand Control Display Messages
Messages will be displayed on the Hand Control whenever the Hand or Foot
controls are operated. No messages will appear when using the Emergency
Override Panel.
Display
• The hand control display can display 2 lines of messages or prompts during
a normal operation.
1. Top line
displays the table orientation.
2. Bottom line
tells operator about condition of table such as battery level,
the position being engaged ie.,Trendelenburg, flex, tilting right, etc.
• The display will also tell the operator if service is required and if a problem
exist an error code will appear such as E01, E02, etc. Write down the error
code number and call a qualified technician, giving him the error code num-
ber.
Messages
• The following messages or prompts may appear:
WAIT..
.
Indicates the microprocessor is “booting up” and checking the status of all
switches and sensors.
NORMAL POSITION
Informs the operator the table is in the normal configuration, head over column.
REVERSE POSITION
Informs the operator the table is in the reverse configuration, head opposite col-
umn.
TO UNLOCK PRESS / ENABLE & UNLOCK
When the operator presses the UNLOCK button only, this informs operator that
the ENABLE button must also be pressed.
HOLD FOR 3 SEC
Informs the operator the ENABLE and UNLOCK buttons must be pressed and
held for 3 seconds.
EQUIPMENT ALERT
The table should not be used until checked by a technician that
was factory trained on service and repair of the table.
Operation
