P746/EN PL//G31 Programmable Logic
(PL) 7-
40 MiCOM P746
Pick-Up
0
0
Output R7
DDB #006
Pick-Up
0
0
Output R8
DDB #007
Pick-Up
0
0
Output R9
DDB #008
Pick-Up
0
0
Output R10
DDB #009
Pick-Up
0
0
Output R11
DDB #010
Pick-Up
0
0
Output R12
DDB #011
Pick-Up
0
0
Output R13
DDB #012
Pick-Up
0
0
Output R14
DDB #013
Pick-Up
0
0
Output R15
DDB #014
Pick-Up
0
0
Output R16
DDB #015
1
1
1
DDB #451
CB Status Alarm
DDB #1697
Z2 In Test Mode
DDB #1696
Z1 In Test Mode
DDB #895
Fault C
DDB #894
Fault B
DDB #893
Fault A
DDB #902
Idiff Trip
DDB #1123
CBF Bktrip Z2
DDB #1122
CBF Bktrip Z1
DDB #1523
Idiff Start Z2
DDB #1522
Idiff Start Z1
DDB #469
Cct Fail CZ Alm
DDB #468
Cct Fail Z2 Alm
DDB #467
Cct Fail Z1 Alm
CBF BkTrip
87BB Trip
Fault zone 2
Fault zone 1
Circuitry Fault
Faulted Phase A
Faulted Phase B
Faulted Phase C
Test Mode
CB Alarm
7
PL
