P746/EN ST/G31 Settings
(ST) 4-
16
MiCOM P746
ST
Setting Range
Menu Text Default Setting
Min. Max.
Step Size
Rly O/P Status 00000000
Duplicate. Displays the status of output relays.
Alarm Status 1 00000000000000000000000000000000
32 bits field give status of first 32 alarms.
Alarm Status 2 00000000
Next 32 alarm status defined.
Alarm Status 3 00000000
Next 16 alarm status defined. Assigned specifically for platform alarms.
Access Level
Displays the current access level (see section P746/EN GS for level description and
access):
Level 0 = read access to some cells (system data and security config columns). Write
access to password entry and LCD contrast
Level 1 = leve 0 + read access to all data and settings, poll measurements. Write access
to some cells (level 1 pasword setting, select event, main and fault, extract
events
Level 2 = level 1 + write access to setting cells that change visibility, setting values
selector, reset indication, demand, statistics and CB data counters and level 2
password setting,
Level 3 = All other settings.
Password Control 2
Sets the menu access level for the relay. This setting can only be changed when level 2
access is enabled.
Password Level 1 ****
Allows user to change password level 1 (password may be any length between 0 and 8
characters long). See section P746/EN CS for password strengthering and validation and
blanck password management.
Password Level 2 ****
Allows user to change password level 2 (password may be any length between 0 and 8
characters long). See section P746/EN CS for password strengthering and validation and
blanck password management.
Password Level 3 ****
Allows user to change password level 3 (password may be any length between 0 and 8
characters long). See section P746/EN CS for password strengthering and validation and
blanck password management.
1.3.2 Date and time
Displays the date and time as well as the battery condition.
Setting Range
Menu Text Default Setting
Min. Max.
Step Size
Date/Time Data
Displays the relay’s current date and time.
IRIG-B Sync Disabled Disabled or Enabled
Enable IRIG-B time synchronization (with Irig-B option).
