1.3.1 System data
This menu provides information for the device and general status of the relay.
Setting Range
Menu Text Default Setting
Min. Max.
Step Size
Language English
The default language used by the device. Selectable as English, French, German,
Russian, Spanish.
Password ****
Device default password.
Sys. Fn. Links 0 1
Setting to allow the fixed function trip LED to be self resetting.
Description MiCOM P746
16 character relay description. Can be edited.
Plant Reference MiCOM
Associated plant description and can be edited.
Model Number P746??????????K
Relay model number. This display cannot be altered.
Serial Number 6 digits + 1 letter
Relay model number. This display cannot be altered.
Frequency 50 Hz 10Hz
Relay set frequency. Settable between 50 and 60Hz
Comms Level 2
Displays the conformance of the relay to the Courier Level 2 comms.
Relay Address 255 0 255 1
Fixed front and first rear port relay address.
Plant Status 00000000000000
Displays the circuit breaker plant status for up to 6 circuit breakers (one box mode) or up
to 18 circuit breakers (three box modes).
Control Status 0000000000000000
Not used.
Active Group 1
Displays the active settings group.
Software Ref. 1
Displays the relay software version including protocol and relay model.
Opto I/P Status 00000000000000000000000000000000
Duplicate. Displays the status of opto inputs (L1 to L32).
Opto I/P Status2 00000000
Duplicate. Displays the status of opto inputs (L33 to L40).
Plant Status 01010101010101
Displays the circuit breaker plant status for up to 6 circuit breakers (from CB1 to CB6 and
Bus CB coupler).
