Schellenberg Smart DRIVE 10 PREMIUM User Manual

36
L PARTS LIST
Part Amount
Garage door drive 1
Rail 1
Hand-held transmitter 1
Door bracket 1
Wall bracket 1
Ceiling mount 2
Release with handle 1
Door arm 1
Mounting material 1
M6 nut 2
M8 nut 4
M6 x 14 Hex screw 2
M8 x 14 Hex screw 4
M8 x 25 axle pin 1
M8 x 90 axle pin 1
M1.8 x 38 split pin 2
U-mounting bracket 2
K TECHNICAL DATA
Model / type
Smart DRIVE 10 PREMIUM /
60912 (DE), 60916 (INT)
Smart DRIVE 14 PREMIUM /
60915 (DE), 60914 (INT)
Power Input 220 – 240 V AC 50/60 Hz 220 – 240 V AC 50/60 Hz
Power output 200 W 245 W
Maximum force 600 N 1.000 N
Speed 0.15 m/sec. 0.15 m/sec.
Lighting LED, 24 V DC LED, 24 V DC
Lighting time 3 min. 3 min.
Coding Hopping code Hopping code
Storm supply transmitter 23 A 12 V battery 23 A 12 V battery
Frequency 433,92 MHz 433,92 MHz
Operating temperature -20° to +40° C -20° to +40° C
Max. Door size 10 m
2
14 m
2
Protection class only for dry rooms only for dry rooms
