www.scheppach.com
26
|
GB
Vibration parameters
Vibration value per EN 12733:2018
Vibration a
h
13.647 m/s²
Uncertainty K
h
1.5 m/s²
8. Unpacking
• Open the packaging and carefully remove the prod-
uct.
• Remove the packaging material, as well as the pack-
aging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport
damage. In the event of complaints the carrier must
be informed immediately. Later claims will not be
recognised.
• If possible, keep the packaging until the expiry of the
warranty period.
• Familiarise yourself with the product by means of the
operating manual before using for the rst time.
• With accessories as well as wearing parts and re-
placement parts use only original parts. Spare parts
can be obtained from your specialist dealer.
• When ordering please provide our article number as
well as type and year of manufacture for the product.
m WARNING!
The product and the packaging material are not
children‘s toys! Do not let children play with plas-
tic bags, lms or small parts! There is a danger of
choking or suocating!
9. Layout
Fitting the wheels (Fig. 3)
• Place the axle cover (14) on the gear shaft, the nar-
row side must face the machine.
• Place the wheel (9) on the gearbox shaft, align it with
the hole and secure it with the bolt (19).
Fitting the mower unit for cutter bar mower (Fig. 4)
• Align the holes of the cutter bar (10) and gear unit and
fix them with bolts and nuts (21+22).
Fitting the handlebar (Fig. 5)
• Align the holes in the handlebar (2) and guide bar
(12).
• Secure the handlebar with screws and nuts (17 + 18).
7. Technical data
Dimensions L x W x H 1265 x 920 x 1300 mm
Sickle bar mower unit
width
880 mm
Number of blades 18 pcs.
Cutting speed 800 m/s
Cut height 30 - 60 mm
Speed 2.52 km/h
Wheel diameter 320 mm
Handlebar height 830 / 970 / 1100 mm
Weight 58 kg
Drive
Type of engine
1-cylinder, 4-stroke OHV
engine
Displacement 196 cm³
Idle speed 1800 - 2200 rpm
Maximum speed 3300 rpm
Engine starter Cable pull
Power 4.2 kW
Fuel
Unleaded petrol from octane
rating 90 and maximum
organic ethanol content
of 5%
Fuel tank capacity 1 l
Required engine oil
SAE 10W-30 / SAE
10W-40
Engine oil tank capacity 0.6 l
Subject to technical changes!
Noise and vibration
m Warning: Noise can have serious eects on your
health. If the machine noise exceeds 85 dB, please
wear suitable hearing protection.
Information on noise level per ISO 11094:1991; EN
ISO 3744
Noise data
Sound power level L
WA
101.6 dB
Sound pressure level L
pA
65.21 dB
Uncertainty K
wa/pA
2.01 dB
