• The pressure relief valve is set and sealed at the
-
tomer service.
6.11.2 Thermal valve
• The thermal valve protects the high-pressure pump
against non-permitted heating in circuit operation
• The thermal valve opens when the water temper-
ature exceeds 55 - 60°C and discharges the hot
water to the outside.
6.12 Residual risks
m CAUTION
Despite intended use, non-obvious residual risks
•
•
7. Technical data
Engine
Displacement 212 cm³
Rated output at 4.3 (5.9) kW (hp)
Nominal speed 3600 rpm
Fuel tank 3.6 l
Fuel Petrol, unleaded
-
gine
0.6 l
SAE10W30
Spark plug F7RTC
Weight 25,5 kg
Water connection
12 mm
-
perature
40 °C
-
sure
0.5 (5) MPa (bar)
Pump
Working pressure 22.1 (221) MPa (bar)
Max. working pres-
sure
24.1 (241) MPa (bar)
9.5 l/min
Thermal valve
opening temper-
ature
55 - 60 °C
Input connection G 3/4 (EU)
Output connection M22x1.5
Cleaning agents
approved for high-pressure
cleaners.
6.9 Hot water and petrol engine devices
m DANGER
•
used. There is a risk of explosion with unsuitable fuels.
• When refuelling devices with petrol engines, make
sure that no fuel gets onto hot surfaces.
• -
tions in the operating manual for devices with petrol
engines.
• When operating the device indoors, ensure that
gases are discharged. (Danger of poisoning)
•
m WARNING
• Danger of burning! Do not bend over or touch the
6.10 Handling fuel
m DANGER
• Do not operate the high-pressure cleaner if fuel has
been spilled, move the device to another location
•
equipment such as stoves, boilers, water heaters,
etc. that have a pilot light or produce sparks.
•
• Do not operate the engine without the silencer and
•
spark arrester.
•
-
er over the intake manifold.
•
-
crease in engine speed.
• Danger of burning! -
• Never bring hands and feet close to moving or ro-
tating parts.
• Danger of poisoning! Device must not be operated
in closed rooms.
• -
gerous.
6.11 Safety devices
be overridden or converted.
6.11.1 Overpressure valve
•
relief valve opens and the high-pressure pump re-
turns the water to the pump suction side. This pre-
vents the permitted working pressure from being
exceeded.
