Characteristic noise emission values (400V~)
sound power level L
WA
98 dB (A)
sound pressure level L
pA
89,8 dB (A)
uncertainly K
WA/pA
3 dB
* S6 40%, continuous operation periodic duty. Iden-
tical duty cycles with a period at load followed by a
period at no load. Running time 10 minutes; duty cy-
cle is 40% of the running time.
Pressure:
The performance level of the built-in hydraulic pump
can reach a short-term pressure level for a splitting
force of up to 7 tons. In the basic setting, hydraulic
splitters are set at the factory to an approx. 10% low-
er output level. For safety reasons, the basic settings
must not be changed by the user.
Please note that external circumstances such as op-
erating and ambient temperature, air pressure and
addition, manufacturing tolerances and maintenance
8. Unpacking
Open the packaging and remove the device carefully.
Remove the packaging material as well as the pack-
aging and transport bracing (if available).
Check that the delivery is complete.
Check the device and accessory parts for transport
damage.
In case of complaints the dealer must be informed
immediately. Subsequent complaints will not be ac-
cepted.
If possible, store the packaging until the warranty pe-
riod has expired.
Read the operating manual to make yourself familiar
with the device prior to using it.
Only use original parts for accessories as well as for
wearing and spare parts. Spare parts are available
from your specialized dealer.
Specify our part numbers as well as the type and year
of construction of the device in your orders.
m ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, lm and small parts! There is a risk of
swallowing and suocation!
• Injury through electric current if incorrect electric
connection leads are used.
• Even when all safety measures are taken, some
remaining hazards which are not yet evident may
still be present.
• Remaining hazards can be minimized by following
the safety instructions as well as the instructions in
the chapter Authorized use and in the entire oper-
ating manual.
• Health hazard due to electrical power, with the use
of improper electrical connection cables.
• -
chine prior to any operations.
• Avoid accidental starts of the machine: Do not
press the start button while inserting the plug into
the socket.
• Use the tools recommended in this manual to ob-
tain the best results from your machine.
• Always keep hands away from the work area when
the machine is running.
7. Technical data
Motor V/Hz 230V / 50Hz 400V / 50Hz
Input P1 W 3000 2100
Output P2 W 2200 1500
Operating mode S6 40% S6 40%
Motor speed 1/min 2800 2800
Phase inverter - yes
Dimensions D/W/H 850 x 915 x
1495
850 x 915 x
1495
Table height 800 mm
Working height 920 mm
Log length
min. - max.
250 - 550 mm
Log diameter
min. - max. :
100 - 300 mm
Power max. tons* 7
Piston stroke 495 mm
Forward speed 4,5 cm/s
Return speed 16,5 cm/s
Oil quantity 3,5 l
Weight approx. 98,5 kg 95,5 kg
Subject to technical changes!
Noise
m Warning:
health. If the machine noise exceeds 85 dB (A),
please wear suitable hearing protection.
Characteristic noise emission values (230V~)
sound power level L
WA
97,4 dB (A)
sound pressure level L
pA
89,8 dB (A)
uncertainly K
WA/pA
3 dB
