• The connection cables for any defective spots
(cracks, cuts etc.).
• The machine for any possible damage.
•
• The hydraulic system for leakage.
• The oil level.
Checking the oil level (g. 13)
The hydraulic unit is a closed system with oil tank, oil
pump and control valve. Check the oil level regularly
before every use. Too low an oil level can damage
the oil pump. The correct oil level is approx. 10 to 20
mm below the oil tank surface.
Note: The level of oil must be checked when the riv-
ing knife is pulled back. If the oil level is at the low-
er notch, then the oil level is at a minimum. Should
this be the case, oil must be immediately added. The
upper notch indicates the maximum oil level. The
machine must be on level ground. Screw in the oil
dipstick fully, to measure the oil level.
Functional test
Test the function before every use.w
Action: Result:
Push both handles towards
below.
Splitting knife goes
down to approx. 10
cm above the table.
Let one handle loose, then
the other.
Splitting knife stops
in the desired po-
sition.
Let both handles loose. Splitting knife
returns to upper
position.
Check the oil level before every use – see chap-
ter “Maintenance“.
Venting (g. 14)
Before working with the log splitter, vent the hydraulic
system.
• Release the venting cap 14 by a few revolutions so
the air can escape from the oil tank.
• Leave the cap open during the operation.
• Before you move the log splitter, close the cap
again in order not to lose any oil.
If the hydraulic system is not vented, the enclosed air
will damage the gaskets and with it the complete log
splitter.
Stroke limit for short logs (g. 14)
Lower splitting knife position about 10 cm above ta-
ble.
• Move splitting knife to the desired position
• Release one operating arm
•
• Release the second operating arm
9. Attachment / Before starting the
equipment
9.1 Fitting the wheels (7) (enclosed accessories
bag A)
•
•
• Fully tighten previously loosened screw.
•
• Secure the wheels on the axle with a split pin
•
• Repeat this process on the other side.
9.2 Fitting the table (5)
•
•
•
tighten the star grip screws previously loosened
9.3 Fitting the complete control arms (10)
(enclosed accessories bag B)
• The control handles on the arms point outwards!
• Insert the hexagon screw and washer through the
• Guide control arm (A) into the rocker switch (B)
• Place the washer (7a) between the control arm and
• From below, now tighten the hexagon screw with
washer and a self-locking nut
• Attention: Tighten the self-locking nut only
moved to the left and right.
• Now fasten the other control arm on the other side
in accordance with the method described
9.4 Fitting the claws (enclosed accessories
bag C)
• Fasten the additional retainers (D) to the claws with
• Make sure that the larger additional retainer is
fastened with the left claw (4).
• Place the adjustable claws on the hexagon nuts
previously attached, and fasten these with the star
• Note that the prongs on the claws must point
m IMPORTANT!
You must fully assemble the appliance before using it
10. Initial operation
Make sure the machine is completely and expertly
assembled. Check before every use:
