Page 1.14
SCHILLER AT-2plus 6-Channel ECG Unit
SERVICE HANDBOOK Issue d May 2002
Chapter 1
Operating Elements
Settings (cont.)
Interpretation settings: N/A:+/- ‘normal/abnormal’ is written (+) or suppressed (-)
U:+/- ‘unconfirmed report’ is written (+) or suppressed (-)
A30:+/- patient age is assumed to be < 30 (-) or >30 (+)
S: +/- low (-) or high (+) sensitivity
For AT-2plus Memory only:
Automatic Save Enabled (+) or Suppressed (-)
Automatic Erase Enabled (+) or Suppressed (-)
Baud Data transmission speed (9600 - 115200 bit/s, see page 1.25)
Com-Type Communication mode, Line or Modem (see page 1.25)
Default Settings
To reset the unit to the basic default settings, proceed as follows:
ALT - 0 - 6 - 6
SETTINGS STANDARD WITH INTERPRETATION
LANGUAGE AS SET AS SET
LEADS STANDARD (S) STANDARD (S)
AUTO FORMAT 1 ECG: 25MM/S, SHORT (O)
ECG : 25MM/S, SHORT (O)
MECG: 2*6 (50MM/S + 1)
MEASUREMENTS:
SUPRESSED (-)
INTERPRETATION:
ENABLED (+)
MARKS: ENABLED (+)
AUTO FORMAT 2 ECG: 25MM/S, LONG (OOO)
ECG : 25MM/S, LONG
(OOO)
MECG: NONE
MEASUREMENTS:
SUPRESSED (-)
INTERPRETATION:
DISABLED (-)
MARKS: ENABLED (+)
RHYTHM LEADS V1 V1, II
AUTOM.
CENTERING
ENABLED (+) ENABLED (+)
PRINTOUT OF
SIGNALS
SEQUENTIAL SEQUENTIAL
BASELINE FILTER
SETTING
0.05HZ 0.05HZ
MAINS FILTER
SETTINGS
50HZ (60HZ) 50HZ (60HZ)
MYOGRAM
FILTER SETTING
35HZ, OFF 35HZ, OFF
MEMORY AND
SERIAL
COMMUNICATIO-
N INTERFACE
OPTION
BAUD RATE 115200 BPS BAUD RATE 115200 BPS
AUTO STORAGE ON (+)
AUTO DELETETION OFF (-)
AUTO STORAGE ON (+)
AUTO DELETETION OFF (-)
TRANS. MODE: LINE TRANS. MODE: LINE
MEMORY
AUTO SAVE ENABLED (+)
AUTO ERASE DISABLED (-)
AUTO SAVE ENABLED (+)
AUTO ERASE DISABLED (-)
INTERPRETATION
SETTINGS
N/A: SUPRESSED (-)
U: ENABLED (+)
A30: UNDER THIRTY (-)
S: LOW (-)
