Schiller AT-2plus - Automatic Mode (ECG) Settings

Page 1.20
SCHILLER AT-2plus 6-Channel ECG Unit
SERVICE HANDBOOK Issue d May 2002
Chapter 1
Operating Elements
Automatic Mode (ECG) Settings
Two separate Auto formats can be defined for the AT-2plus. When defining auto format 1 the key
sequence ALT `1` precedes the setting. When defining auto format 2 the key sequence ALT `2`
precedes the setting.
Automatic ECG Format
Entry Key
Sequence
Setup Format
ALT
1
Commence Setup for
Auto format 1
2
Commence Setup for
Auto format 2
The automatic mode formats are detailed on the following pages. The ECG format is set as follows:
ECG Format
Entry Key Sequence Printout Confirm
ALT 1 or 2 1
1 1page x 12 leads at 25mm/s
Press
STOP key
2
One page with the first 8 leads
printed for 5s and the last 4
leads printed for 10s
5 No leads printed
6
Leads are printed in short form
(1 sheet)
7
Leads are printed in long form
(2 sheets)
8 Chart Speed 25mm/s
9 Chart Speed 50mm/s
0
Leads are printed in format 4
* 3(25mm/s) + 1
rhythm(25mm/s)
