6.10.2 Creating the PS program
PROTECT-PSCsw is required to create the PS program. After stipulating the sys-
tem configuration, the ladder diagram can be selected in the project window in the
[ProgramS / LD / Ladder Plan] path.
After creation the program must be stored whereby a logical check and translation
is performed.
6.10.3 Creating the PN program
PROTECT-PSCsw is required to create the PN program. After stipulating the sys-
tem configuration, the ladder diagram can be selected in the project window in the
[ProgramS / LD / Ladder Plan] path.
After creation the program must be stored whereby a translation is performed.
For debug purposes it is possible under menu entry [Setup]-[I/O Compulsion
ON/OFF] to set the following specifiers (see Chapter 3.7.6) insofar as these have
not been set in the PN program.
• M flag
• K flag
