Overview|Display and buttons in operation region
12 Operating panel Integral MAP|User manual B-HB-0133EN
Site information for a detector zone
SITE INFO
ZONE 103
CUSTOMER TEXT FOR ZONE 103
E.G. BUILDING, ROOM
0000 0000 0001 0000 0001
3.3.2 Numerical keypad and navigation buttons
Numerical keypad and navigation buttons
X
for entering values and navigation.
Enter elements numbers or other values using the numerical buttons of the keypad.
Structured entry: Separate element numbers with a slash / for example detector zone and
detector (4/1).
Scroll button E for selecting the previous list entry (scroll up in the list). Scroll button F
for selecting the next list entry (scroll down in the list).
Delete button C for deleting the previous character.
Entry button D for confirming an entry.
3.3.3 Information and menu
3.3.3.1 Site information
Pressing the button Site Info
J
displays site information.
Site information can be called up for each element when in list view or element view. A
customer-specific programmed text is displayed, e.g. 1ST FLOOR, CONFERENCE ROOM,
ROOM 25.
3.3.3.2 Additional information
Pressing the button Additional Information
Y
displays additional information.
In list view or element view, additional information can be called up for each element,
e.g. detector zone, detector number, date and time or in case of an event, e.g. alarm,
fault, disablement or actuation.
3.3.3.3 Authorisation
Pressing the button Access Code
K
enables entering the access code for a higher au-
thorisation level. The LED next to the button lights up, as soon as a level higher than ac-
cess level 1 is entered. Further Information: Chapter Operation release (authorisation
levels), Page22
3.3.3.4 Menu
Pressing the button Menu
a
opens the menu for additional options. Available functions
depend on programming and the authorisation level. Further Information: Chapter Menu
functions, Page26
