SPECIFICATIONS
HF255 HF295
Inside Width Below Flare.............................................................. 60” 60”
Inside Width Above Flare............................................................. 68” 68”
Inside Height.................................................................................. 45” 48”
Inside Length Below Flare............................................................ 156” 186”
Inside Length Above Flare........................................................... 164” 194”
Loading Height Less 10” Sideboards......................................... 79” 84”
Overall Width, Trailer Unit............................................................ 95” 98”
Overall Width, Trailer Unit, Optional 4’ Extension..................... 95” 102”
Overall Width, Truck Mount......................................................... 88”
Overall Length............................................................................... 233” 264”
Overall Height................................................................................ 79” 84”
Cross Conveyor Width.................................................................. 26” 26”
Cross Conveyor Depth.................................................................. 10” 10”
Weight, 22.5” Tires, Fold-Up Extension...................................... 3300 lbs. 4615 lbs.
Hitch Weight When Empty, Approx............................................. 680 lbs. 800 lbs.
Axle Spindle Size........................................................................... 2-3/4” 2-3/4”
Wheel Size, Standard.................................................................... 22.8” x 8” 385/65R 22.5-15
Box Capacity, Less Sideboards.................................................. 255 cu ft. 295 cu ft.
204 bu. 247 bu.
Box Capacity With 10” Sideboards............................................. 322 cu ft. 345 cu ft.
258 bu. 277 bu.
SERIAL NUMBER AND MODEL NUMBER
The Serial Number and the Model Number of the Schuler HF Feeder is found on the rear, right hand
frame of the wagon. The serial number is stamped on a plate riveted into the frame just above the
spring tightener. The model Number of the HF Feeder Wagon is located on the front upper right hand
corner of the wagon.
-2-
