DISCHARGE CONVEYOR CHAIN ADJUSTMENT
Lower 4’ feeder extension down to the lowest position. Place a 1-1/2” tall block under a
crossbar 2’ back from the outer end of the 4’ feeder extension. Tighten conveyor chain so that
crossbar is snug on the block but can still be removed by hand from under the crossbar.
Make sure conveyor chain is equal tightness on both sides by sliding block under the
crossbar close to each side chain. Be sure and remove block before operating hay feeder.
If shaft has reached the back of the slot then loosen chain on both sides and remove a link
from each side. Reconnect chains and tighten according to paragraph above.
-15-
