LUBRICATION
PTO
Grease until it purges, every 8 hours of use.
U-Joints Cross – Page 4, Ref. 2
Cardan tube slip sleeve – Page 4, Ref. 5, 6
PTO INPUT SHAFT
Lubricate 1 pump of grease every 50 hours of use.
Flangette bearing – Pages 12, Ref. 23
Flange bearing – Pages 12, Ref. 14
DRIVE BELT TIGHTENER
Lubricate 1 pump of grease every 25 hours of use.
Idler pulley tightener arm – Pages 12, Ref. 8
ROLLER CHAIN TIGHTENER
Lubricate 1 pump of grease every 25 hours of use.
Pivot arm roller chain tightener – Page 14, Ref. 21.
Page 18, Ref 32.
FLOOR APRON DRIVE
Lubricate 1 pump of grease every 25 hours of use.
Bearing cast sleeve – Page 20, Ref. 6.
FLOOR APRON IDLER
Lubricate 1 pump of grease every 25 hours of use.
Sprocket, cast – Page 32, Ref 2.
WHEEL BEARINGS
Repack wheel bearings once a year or every 1000 hours of operation
HF255/HF295 wheel bearings – Page 10, Ref. 4 & 8.
BEATER DRIVE AND IDLER
Lubricate 1 pump of grease every 25 hours of use.
Bearing – Page 14, Ref. 6.
CROSS CONVEYOR DRIVE AND IDLER
Lubricate 1 pump of grease every 50 hours of use.
Bearing – Page 26 & 28, Ref. 3 & 35 respectively.
JACK SHAFT BEARINGS
Lubricate 1 pump of grease every 25 hours of use.
Bearing – Page 14 & 15, Ref. 6
Bearing – Page 18 & 19, Ref. 3
-18-
