- 7 -
V-BELT DRIVE HF255
HF-000040
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
0-411012
PTO ALIGNMENT PULLEY & SPROCKET HF 1 B 1/4 KW
2
2
13070-1C06
FLAT IDLER, C-BELT, 7 OD, 5/8 BORE
3
1
13134-1C10
V-PULLEY, C-BELT, 13 1/2 OD, 1 1/4 B, 1/4 KW
4
1
13070-1C05
V-BELT IDLER, C-BELT, 7 OD, 5/8 BORE
5
1
1501C-1360
V-BELT, C-136
